FEATURES
- Maximum working pressure:
3000 psi (210 bar) at 100°F (38°C) - Working temperature:
Up to 464°F to (240°C) with PTFE packing - Black Led handle gives quarter turn rust-free operation.
- Valves with PTFE seats are supplied.
- The stem with shoulder provides blowout proof design to
maintain seal integrity at all pressure. - Optional sour gas service conforms to NACE MR0175.
- Ball valves are hydrostatic tested at the full rated pressure and
low pressure pneumatic at 70 psi. - 100% factory tested
- Material: SS304L/SS316L, Monel, Hastelloy, Inconel & Duplex
- Material Traceability
