Needle Valves Screwed Bonnet Design
₹1
Global Valves According to DIN/SAE/ISO/UNF Standard.
- Maximum working pressure:
7200 psi (512 bar) - Working temperature:
-20°C to 240°C - PTFE packings can be adjusted to extend the valve life.
- Packing is optional with graphite for high temperature to 450°C
- Stem threads are rolled and lubricated to prevent galling and reduce
operating torque. - Hydro test performed with pure water at 1.5 times of
working pressure. - 100% factory tested
- Material: Only CS (White Zinc Plated)
- Material Traceability
- Size 1/4 to 2″ pipe thread
- Variety of Thread type : NPT, BSP, SAE & Metric
