FEATURES
- Maximum working pressure:
6000 psi (414bar) at 100°F (38°C)
10000 psi (690bar) at 100°F (38°C) - Working temperature:
-65°F (-54°C) to 464°F (240°C)
-65°F (-54°C) to 842°F (450°C) - PTFE packings can be adjusted to extend the valve life.
- Packing is optional with graphite for high temperature to 450°C
- Stem threads are rolled and lubricated to prevent galling and reduce operating torque.
- Optional sour gas service conforms to NACE MR0175.
- Hydro test performed with pure water at 1.5 times of working pressure.
- Bonnet Lock pin Prevents accidental Removal while in service.
- 100% factory tested
- Material: SS304L/SS316L, Monel, Hastelloy, Inconel & Duplex
- Material Traceability
